Horizontal type Gas oil fuel 0 5 ton 500kg Small steam boiler 500 kg hr

FOB Price:

US 5000-50000 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

5000 Ton/Tons per Year

Port:

Shanghai,Qingdao

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,D/P,T/T,Western Union

Brand:

Yuanda Boiler

Products Model:

WNS

Products Details
Company Profile

Quick Details

Brand Name: Yuanda Boiler

Model Number: WNS

Place of Origin: Henan, China (Mainland)

Packaging & Delivery

Packaging Details: seaworthy packing
Delivery Detail: 30 days

Specifications

Gas/oil furnace horizontal 0.5 ton 500kg Small steam boiler 500 kg/hr

Product Description

capacity :0.5 ton steam per hour,500kg steam boiler

gasconsumption:40m3 per hour

horizontal type,3 pass fire tube structure

1,WNS series Gas fired steam boiler realize high efficient heat transfer, sufficient burning with brand burner, environment protection

2,Applied international latest technology for big volume combustion room design, and use brand burner machine

3,Corrugated furnace design make large heat transfer area and protect furnace

4,Using spirally corrugated tube , 1-2 faster heat transfer efficiency and remove hidden danger of welding cracks

5,Applied wet-back structure thatn can reduce faults rate and maintenance cost

6,Equipped with protection devices for overheating, overpressure, lacking water, leak detection, flameout etc.

0.5 ton small steam boiler specifications

Gas oil fired steam boiler model			WNS0.5- 1.0-Y(Q)
Rated evaporating capacity		t/h	0.5
Rated pressure		MPa	1
Feed water temperature		° C	20
Rated steam temperature		° C	184
Consumption	Light diesel(10240kcal/h)	Kg/h	32
	Heavy oil (10000kcal/h)	Kg/h	30.3
	Natural gas (8500kcal/h)	m 3 /h	38
	Liquid gas (24000kcal/h)	m 3 /h	14
	City gas (3800kcal/h)	m 3 /h	85
Thermal efficiency		%	94
Main part weight		t	3t
Main part Size(mm)		Length	3m
		Width	1.8
		Height	1.9

Boiler in stock

Our Services

Warranty:

One-year warranty and full-life service for all of our steam boilers

Boiler spare parts service:

A full range of original spare parts are available for all Yuanda boilers

Packaging & Shipping

Boiler Structure

Corrugated furnace,and 3 pass fire tube structure
